| Artikelnummer: |
Ausführung: |
DN: |
Size: |
Inch: |
Anschlussgewinde: |
Betriebsdruck: |
Abmessung H mm: |
Abmessung L mm: |
| 20340012501 |
PN05 AGR1/8" |
5 |
3 |
3/16" |
BSPP, zylindrisch R1/8"-28 |
415 bar |
20mm |
45mm |
| 20340012502 |
PN05 AGR1/4" |
5 |
3 |
3/16" |
BSPP, zylindrisch R1/4"-19 |
415 bar |
24mm |
49mm |
| 20340012503 |
PN06 AGR1/8" |
6 |
4 |
1/4" |
BSPP, zylindrisch R1/8"-28 |
415 bar |
20mm |
48mm |
| 20340012504 |
PN06 AGR1/4" |
6 |
4 |
1/4" |
BSPP, zylindrisch R1/4"-19 |
450 bar |
25mm |
53mm |
| 20340012505 |
PN06 AGR3/8" |
6 |
4 |
1/4" |
BSPP, zylindrisch R3/8"-19 |
450 bar |
27mm |
55mm |
| 20340012506 |
PN06 AGR1/2" |
6 |
4 |
1/4" |
BSPP, zylindrisch R1/2"-14 |
450 bar |
32mm |
60mm |
| 20340012507 |
PN08 AGR1/4" |
8 |
5 |
5/16" |
BSPP, zylindrisch R1/4"-19 |
350 bar |
25mm |
53mm |
| 20340012508 |
PN08 AGR3/8" |
8 |
5 |
5/16" |
BSPP, zylindrisch R3/8"-19 |
350 bar |
27mm |
55mm |
| 20340012509 |
PN08 AGR1/2" |
8 |
5 |
5/16" |
BSPP, zylindrisch R1/2"-14 |
350 bar |
32mm |
60mm |
| 20340012510 |
PN10 AGR1/4" |
10 |
6 |
3/8" |
BSPP, zylindrisch R1/4"-19 |
450 bar |
25mm |
55mm |
| 20340012511 |
PN10 AGR3/8" |
10 |
6 |
3/8" |
BSPP, zylindrisch R3/8"-19 |
450 bar |
27mm |
58mm |
| 20340012512 |
PN10 AGR1/2" |
10 |
6 |
3/8" |
BSPP, zylindrisch R1/2"-14 |
450 bar |
32mm |
62mm |
| 20340012513 |
PN12 AGR3/8" |
12 |
8 |
1/2" |
BSPP, zylindrisch R3/8"-19 |
415 bar |
28mm |
61mm |
| 20340012514 |
PN12 AGR1/2" |
12 |
8 |
1/2" |
BSPP, zylindrisch R1/2"-14 |
415 bar |
33mm |
66mm |
| 20340012515 |
PN12 AGR5/8" |
12 |
8 |
1/2" |
BSPP, zylindrisch R5/8"-14 |
415 bar |
35mm |
68mm |
| 20340012516 |
PN12 AGR3/4" |
12 |
8 |
1/2" |
BSPP, zylindrisch R3/4"-14 |
415 bar |
36mm |
69mm |
| 20340012517 |
PN16 AGR1/2" |
16 |
10 |
5/8" |
BSPP, zylindrisch R1/2"-14 |
350 bar |
33mm |
69mm |
| 20340012518 |
PN16 AGR5/8" |
16 |
10 |
5/8" |
BSPP zylindrisch R5/8"-14 |
350 bar |
35mm |
71mm |
| 20340012519 |
PN16 AGR3/4" |
16 |
10 |
5/8" |
BSPP, zylindrisch R3/4"-14 |
350 bar |
36mm |
72mm |
| 20340012520 |
PN19 AGR1/2" |
19 |
12 |
3/4" |
BSPP, zylindrisch R1/2"-14 |
350 bar |
34mm |
74mm |
| 20340012521 |
PN19 AGR5/8" |
19 |
12 |
3/4" |
BSPP, zylindrisch R5/8"-14 |
350 bar |
36mm |
76mm |
| 20340012522 |
PN19 AGR3/4" |
19 |
12 |
3/4" |
BSPP, zylindrisch R3/4"-14 |
350 bar |
37mm |
77mm |
| 20340012523 |
PN19 AGR1" |
19 |
12 |
3/4" |
BSPP, zylindrisch R1"-11 |
350 bar |
42mm |
82mm |
| 20340012524 |
PN25 AGR3/4" |
25 |
16 |
1" |
BSPP, zylindrisch R3/4"-14 |
280 bar |
38mm |
89mm |
| 20340012525 |
PN25 AGR1" |
25 |
16 |
1" |
BSPP, zylindrisch R1"-11 |
280 bar |
43mm |
94mm |
| 20340012526 |
PN25 AGR1.1/4" |
25 |
16 |
1" |
BSPP, zylindrisch R1.1/4"-11 |
280 bar |
46mm |
97mm |
| 20340012527 |
PN31 AGR1" |
31 |
20 |
1.1/4" |
BSPP, zylindrisch R1"-11 |
210 bar |
42mm |
102mm |
| 20340012528 |
PN31 AGR1.1/4" |
31 |
20 |
1.1/4" |
BSPP, zylindrisch R1.1/4"-11 |
210 bar |
47mm |
105mm |
| 20340012529 |
PN31 AGR1.1/2" |
31 |
20 |
1.1/4" |
BSPP, zylindrisch R1.1/2"-11 |
210 bar |
50mm |
108mm |
| 20340012530 |
PN38 AGR1.1/2" SW55 |
38 |
24 |
1.1/2" |
BSPP, zylindrisch R1.1/2"-11 |
185 bar |
50mm |
115mm |
| 20340012531 |
PN38 AGR1.1/2" SW70 |
38 |
24 |
1.1/2" |
BSPP, zylindrisch R2"-11 |
185 bar |
55mm |
119mm |
| 20340012532 |
PN51 AGR1.1/2" |
51 |
32 |
2" |
BSPP, zylindrisch R1.1/2"-11 |
165 bar |
54mm |
130mm |
| 20340012533 |
PN51 AGR2" |
51 |
32 |
2" |
BSPP, zylindrisch R2"-11 |
165 bar |
56mm |
126mm |
| 20340012534 |
PN63 AGR2.1/2" |
63 |
40 |
2.1/2" |
BSPP, zylindrisch R2.1/2"-11 |
69 bar |
60mm |
132mm |
| 20340012535 |
PN76 AGR3" |
76 |
48 |
3" |
BSPP, zylindrisch R3"-11 |
50 bar |
69mm |
136mm |
