| Artikelnummer: |
Ausführung: |
Anschlussgewinde: |
Anschlussgewinde Ø in mm: |
Innengewinde: |
Innengewinde Ø in mm: |
Betriebsdruck: |
| 40420015101 |
GAI-AGJ7/16 IG1/8" |
7/16"-20 UNF |
11,07mm |
BSPP, zylindrisch G1/8"-28 |
8,57mm |
350 bar |
| 40420015102 |
GAI-AGJ7/16 IG1/4" |
7/16"-20 UNF |
11,07mm |
BSPP, zylindrisch G1/4"-19 |
11,45mm |
350 bar |
| 40420015103 |
GAI-AGJ7/16 IG3/8" |
7/16"-20 UNF |
11,07mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
420 bar |
| 40420015104 |
GAI-AGJ7/16 IG3/4" |
7/16"-20 UNF |
11,07mm |
BSPP, zylindrisch G3/4"-14 |
24,12mm |
420 bar |
| 40420015105 |
GAI-AGJ1/2 IG1/8" |
1/2"-20 UN |
12,70mm |
BSPP, zylindrisch G1/8"-28 |
8,57mm |
350 bar |
| 40420015106 |
GAI-AGJ1/2 IG1/4" |
1/2"-20 UN |
12,70mm |
BSPP, zylindrisch G1/4"-19 |
11,45mm |
350 bar |
| 40420015107 |
GAI-AGJ1/2 IG3/8" |
1/2"-20 UN |
12,70mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
420 bar |
| 40420015108 |
GAI-AGJ9/16 IG1/8" |
9/16"-18 UNF |
14,25mm |
BSPP, zylindrisch G1/8"-28 |
8,57mm |
315 bar |
| 40420015109 |
GAI-AGJ9/16 IG1/4" |
9/16"-18 UNF |
14,25mm |
BSPP, zylindrisch G1/4"-19 |
11,45mm |
350 bar |
| 40420015110 |
GAI-AGJ9/16 IG3/8" |
9/16"-18 UNF |
14,25mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
350 bar |
| 40420015111 |
GAI-AGJ9/16 IG1/2" |
9/16"-18 UNF |
14,25mm |
BSPP, zylindrisch G1/2"-14 |
18,63mm |
350 bar |
| 40420015112 |
GAI-AGJ3/4 IG3/8" |
3/4"-16 UNF |
19,00mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
350 bar |
| 40420015113 |
GAI-AGJ3/4 IG1/2" |
3/4"-16 UNF |
19,00mm |
BSPP, zylindrisch G1/2"-14 |
18,63mm |
350 bar |
| 40420015114 |
GAI-AGJ3/4 IG5/8" |
3/4"-16 UNF |
19,00mm |
BSPP, zylindrisch G5/8"-14 |
20,59mm |
350 bar |
| 40420015115 |
GAI-AGJ3/4 IG3/4" |
3/4"-16 UNF |
19,00mm |
BSPP, zylindrisch G3/4"-14 |
24,12mm |
250 bar |
| 40420015116 |
GAI-AGJ7/8 IG3/8" |
7/8"-14 UNF |
22,17mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
350 bar |
| 40420015117 |
GAI-AGJ7/8 IG1/2" |
7/8"-14 UNF |
22,17mm |
BSPP, zylindrisch G1/2"-14 |
18,63mm |
350 bar |
| 40420015118 |
GAI-AGJ7/8 IG5/8" |
7/8"-14 UNF |
22,17mm |
BSPP, zylindrisch G5/8"-14 |
20,59mm |
350 bar |
| 40420015119 |
GAI-AGJ1.1/16 IG3/8" |
1.1/16"-12 UN |
26,95mm |
BSPP, zylindrisch G3/8"-19 |
14,95mm |
320 bar |
| 40420015120 |
GAI-AGJ1.1/16 IG1/2" |
1.1/16"-12 UN |
26,95mm |
BSPP, zylindrisch G1/2"-14 |
18,63mm |
350 bar |
| 40420015121 |
GAI-AGJ1.1/16 IG3/4" |
1.1/16"-12 UN |
26,95mm |
BSPP, zylindrisch G3/4"-14 |
24,12mm |
350 bar |
| 40420015122 |
GAI-AGJ1.1/16 IG1" |
1.1/16"-12 UN |
26,95mm |
BSPP, zylindrisch G1"-11 |
30,29mm |
320 bar |
| 40420015123 |
GAI-AGJ1.3/16 IG3/4" |
1.3/16"-12 UN |
30,10mm |
BSPP, zylindrisch G3/4"-14 |
24,12mm |
315 bar |
| 40420015124 |
GAI-AGJ1.5/16 IG3/4" |
1.5/16"-12 UN |
33,30mm |
BSPP, zylindrisch G3/4"-14 |
24,12mm |
280 bar |
| 40420015125 |
GAI-AGJ1.5/16 IG1" |
1.5/16"-12 UN |
33,30mm |
BSPP, zylindrisch G1"-11 |
30,29mm |
280 bar |
| 40420015126 |
GAI-AGJ1.5/8 IG1" |
1.5/8"-12 UN |
41,22mm |
BSPP, zylindrisch G1"-11 |
30,29mm |
250 bar |
| 40420015127 |
GAI-AGJ1.5/8 IG1.1/4" |
1.5/8"-12 UN |
41,22mm |
BSPP, zylindrisch G1.1/4"-11 |
38,95mm |
250 bar |
| 40420015128 |
GAI-AGJ1.7/8 IG1.1/4" |
1.7/8"-12 UN |
47,57mm |
BSPP, zylindrisch G1.1/4"-11 |
38,95mm |
250 bar |
| 40420015129 |
GAI-AGJ1.7/8 IG1.1/2" |
1.7/8"-12 UN |
47,57mm |
BSPP, zylindrisch G1.1/2"-11 |
44,85mm |
250 bar |
| 40420015130 |
GAI-AGJ2.1/2 IG2" |
2.1/2"- 12 UN |
63,45mm |
BSPP, zylindrisch G2"-11 |
56,66mm |
125 bar |
